Description:

• Exceptional Efficiency: Maximum efficiency up to 98.8%, , minimizing losses and maximizing the return on investment for solar installations.
• Multiple MPPT Channels: 6 Power Point Tracking (MPPT) channels
• Wide MPPT Voltage Range: 200-850V
• Advanced Safety and Protection Features: DC polarity reverse connection protection, AC output overcurrent and overvoltage protection, AC output short circuit protection, thermal protection, and ground fault current monitoring
• PID Mitigation and Zero Export Functionality: helps to maintain the performance of the solar panels over time
• Robust Design: Encased in an IP65-rated enclosure, withstand in harsh environmental conditions and operate within a wide temperature range of -25°C to +60°C, with derating above 45°C
• Comprehensive Grid Compliance
• Versatile Communication and Monitoring Options: supports various communication interfaces such as GPRS, Wi-Fi, Bluetooth, 4G, LAN, RS485, and RS232.
• Lightweight and Compact: (approximately 81 kg), with dimensions of 824×516×312.7 mm
• Grid Support and Power Quality

Specifications:

• Rated AC Output Active Power: 100kW
• Maximum PV Input Power: Up to 150kW
• Grid Connection Form: 3L/N/PE
• Rated Output Voltage: 220/380V, 230/400V
• THD: Total Current Harmonic Distortion <3%
• Power Factor Adjustment Range: 0.8 leading to 0.8 lagging
• Max. 6 MPP trackers, Max. efficiency up to 98.8%
• Dimensions: 824×516×312.7 mm
• Weight: approximately 81 kg
