Features:

• 11 kV to 400 V conversion : Converts medium-voltage electricity into low-voltage power for buildings, factories, and equipment.
• High efficiency
• Natural cooling — ONAN: Uses natural circulation of oil and air for cooling, without cooling fans or pumps.
• Operation up to +45°C ambient: Designed for hot conditions within the stated rating. Correct ventilation and installation remain essential.
• C5 corrosion protection: for harsh or coastal environments.
• Dyn11 connection: A common three-phase distribution configuration, with a neutral connection on the low-voltage side.

Specifications:

• Rated Power: 50 kVA
• High Voltage: 11 kV
• Low Voltage: 0.4 kV
• Vector Group: Dyn11
• NO-Load Loss: 190 W
• Load Loss @75°C: 1250 W
• Efficiency @100% Load: 97%
• Efficiency @50% Load: 97.8%
• Colong Type: ONAN
• Insulation Class: A
• Ambient Temp Range: -45℃ to +45℃
• Corrosion Protection: C5
• Total Weight: 400 Kg
• Dimensions (L×W×H): 1080×790×1030 mm
• Noise Level db: 50 A
• Certifications: UL
