Features:

• Flexible capacity from 16kWh to 768kWh
• Easy Installation: Easy power output expansion & Compact size and high energy density
• Safety and Reliability: Excellent safety of LiFePO4 battery cell, High cycle stability and long lifespan, & Whole system warranty
• Smart O&M: Remote diagnosis and upgrade & Saving and querying fault records

Specifications:

• Battery type: LiFePO4
• Nominal voltage : 51.2V
• Normal capacity: 16kWh
• Usable capacity: 15.3kWh
• Operating voltage: 40~58.4V
• Max. Charge/Discharge current: 150Af200A
• Pea k charging/discharging current: 700N200us
• DOD: 95%
• Dimension (W/H/D): 44018941265mm
• Weight: 120±2kg
• IP Protection: IP 20
• Cycle life: 6000 ( 0.5C , 80% DOD, @25 °C)
• System connection: Max. 48 pcs in parallel
