Description:

• Cutting-edge three-phase string inverters engineered for high performance in both commercial and industrial-scale solar power installations.
• Highest Efficiency:up to 98.8%
• Eight MPPT Trackers:The eight Maximum Power Point Tracking (MPPT) channels enable precise power optimization even under varying solar irradiation conditions, ensuring each solar panel string operates at its highest potential.
• Zero Export and VSG Applications: prevents excess generated energy from being fed back into the grid and enhances grid stability
• Wide MPPT Voltage Range: from 200 V to 1000 V
• Anti-PID Function (Optional): helps protect the solar modules from performance losses, thereby extending their operational lifespan and maintaining higher power output.
• Advanced Protection Mechanisms
• Flexible Communication and Monitoring
• Robust Design: Encased in an IP65-rated enclosure, withstand in harsh environmental conditions and operate within a wide temperature range of -25°C to +60°C, with derating above 45°C
• Compliance and Certification: Meets international safety and performance standards

Specifications:

• 8 MPP trackers, Max. effiffifficiency up to 98.8%
• Maximum PV Input Power: up to 204 kW
• Max. PV Input Voltage of 1100 V and start-up voltage of 250 V
• Rated AC Output Active Power: 136kW
• Total Current Harmonic Distortion (THDi) is kept under 3%
• Dimensions WxHxD: 1006 x 516 x 325.5mm (excluding connectors and brackets)
• Weight: 103 Kg
